Italpresse Matrix 2V Membrane Press
The Italpresse Matrix 2V membrane press is a high-performance positive pressure system designed for efficient and consistent lamination of flat and three-dimensional components. Built with Italpresse’s proven engineering, this machine delivers reliable results in demanding production environments.
The Matrix 2V utilizes advanced membrane pressing technology to apply uniform pressure across complex shapes, making it ideal for laminating MDF, particleboard, and composite panels with PVC and other decorative materials. Its 2V (two-tray) configuration allows one tray to be processed inside the press while the second tray is simultaneously unloaded and reloaded, improving workflow efficiency and minimizing downtime between cycles.
Designed for precision and repeatability, the press produces excellent adhesion and surface quality, even on intricate profiles. Its solid construction and modern control system make it well suited for both high-volume production and custom manufacturing applications.
Common applications include:
- Cabinet doors and panels
- Furniture components
- Architectural millwork
- 3D laminated parts
This machine is an excellent solution for manufacturers looking to increase throughput while maintaining consistent, high-quality finishing results.
Manufacturer
ItalPresse
Model
MATRIX 2V 14.5-28
Year
2016
Condition
Good
| Machine Type | Positive Pressure Membrane Presse |
|---|---|
| Pin Sytem | Automatic Piin System 29.5mm Spacing |
| Tray Configuration | 2-Tray (2V) Shuttle System |
| Unloading System | Barrel Unloading System to Conveyor |
| Platen Size | 1450 x 2800mm (50" x 110.2") |
| Working Area | 1220 x 2575mm (48" x 101.3") |
| Maximum Platen Temperature | 150°C |
| Chamber Height | 55mm (2.1") |
| Max Part Height (with pins) | 40mm (1.5" |
| Scanner Drive | Servo Driven |
| Tray Shuttle Drive | Servo Driven |
| Servo System | Siemens S120 Drives with Siemens Servo Motors |
| HMI | Windows PC-Based with Full Graphics and Diagnostics |
| PLC | Siemens S7 PLC |
| Deep Tray Option | Press operates in single-tray mode when installed |
| Max Material Thickness (Deep Tray) | Up to ~2.5" |
Nationwide Freight
We arrange transport to any location in the continental United States. International shipping available on request.
Rigging & Loading
We can assist coordinating rigging crews and flatbed or step-deck carriers for heavy equipment.
Customer Pickup
You're welcome to inspect and pick up the machine in person. Contact us to schedule.
All specifications are subject to buyer verification. The Machine Warehouse, LLC is not responsible for errors or omissions.
